SGABELLI PIEGHEVOLI

FOLDING STOOL

  • Sturdy folding step stool for industrial use
  • Entirely made of anodised aluminium
  • Available in a standard version with or without protection
  • Differs from the standard step stool (GRS) in that the bigger uprights make it sturdier and hence better suited to withstand the loads and stresses typically associated with the industrial sector
  • Wide anti-slip corrugated 200 x 360 mm steps
  • Universal joints for stability
  • Feet with anti-slip rubber tips
  • Ideally suited for heavy duty loading/unloading operations and maintenance works at height because the large tread and the 45- degree slant make it possible to go up and down the ladder without holding on to it
Read More
B2-S PIOLI

LEANING/ FIXED LADDER FOR LOFTS


Single section leaning ladder
  • Ideal for loft access
  • Available with 25 mm rungs
  • Anti-slip rubber feet
  • Side handrail
  • Read More
    B2 PIOLI

    LEANING LADDER





    • Single section leaning ladder
    • Sturdy corrugated anti-slip non tilting 25 mm steps secured to the uprights of the ladder with self-locking screws
    • Piedi antiscivolo



    Read More

    LEANING/ FIXED LADDER FOR LOFTS

    • Single section leaning ladder

    • Ideal for loft access
    • Available with 80 mm steps
    • Anti-slip rubber feet
    • Side handrail
    Read More
    PEDANA RICHIUDIBILE - STEP SPECIALE

    FOLDING PLATFORM

    • SPECIAL CUSTOMIZED PLATFORM
    • WE DESIGN AND MANIFACTURE ANY TIPE OF TAILOR MADE PLATFORM, FULLY CUSTOMISED AS A FUNCTION OF CUSTOMER NEEDS.
    • AS A FUNCTION OF DIMENSIONAL AND STRUCTURAL REQUIREMENTS AND INTENDED USE, They can also be made ACCORDING TO STANDARD  . OUR TECHNICAL OFFICE IS AT YOUR COMPLETE DISPOSAL FOR ADVICE, PROJECTS AND QUOTATIONS.



    Read More

    PICKING LADDER

    Special ladders made to measure, with height adjustable object tray. Ideal for material lifting applications.

    WE DESIGN AND CONSTRUCT ANY TYPE OF TAILOR MADE LADDER, FULLY CUSTOMISED AS A FUNCTION OF CUSTOMER NEEDS.   AS A FUNCTION OF DIMENSIONAL AND STRUCTURAL REQUIREMENTS AND INTENDED USE, THEY CAN ALSO BE MADE ACCORDING TO STANDARD  or

    OUR TECHNICAL OFFICE IS AT YOUR COMPLETE DISPOSAL FOR ADVICE, PROJECTS AND QUOTATIONS.

    Video

    Read More

    FIXED PODIUM LADDER

    • Fixed podium ladder equipped with a comfortable platform and safety railings
    • Welded structure that is extremely rigid and stable
    • Sturdy anti-slip corrugated 130 mm steps
    • 250 mm risers
    • Protective railing on three sides pursuant to the applicable regulations
    • Object tray
    • Comfortable 500 x 400 mm platform with non-slip surface, with foot stop on three sides pursuant to the applicable regulations
    • Base with anti-tipping board on the front and sides, and two fixed bearing wheels mounted so that the ladder rests on four feet when in use and the wheels will only come into play when the ladder is raised
    • Ideal for use as cemetery ladders

    * The characteristics described above apply to the aluminium versions

    Read More
    Scale con gabbia

    LADDER WITH SAFETY CAGE

    We design and manufacture Ladders with Safety Cage for access to roofs, machinery, silos, and high points in general.
    The general characteristics are proposed as a function of individual needs, in accordance with the applicable regulations



    Our technical office is at your complete disposal
    for advice, projects and quotations.



    Send us the measurements of the ladder with safety cage you have in mind, specifying the height between floors, and, if possible, attach a sketch, showing any projections, eaves, cornices, obstacles, parapets, etc.
    Read More

    TANK LADDER





    • Cantilever ladder for maintenance of tanks, tanker trucks, vehicles, etc.
    • Equipped with a comfortable platform and protective railings
    • Welded structure for optimal rigidity and stability
    • Sturdy 150 mm steps in anti-slip, oil, ice and footwear proof grate with draining slots for water and liquid products
    • 250 mm risers
    • Railings on three sides pursuant to the applicable regulations
    • Comfortable 600 x 600 mm platform with anti-slip grate floor, foot stop on three sides pursuant to the applicable regulations
    • Front opening to access the platform, with rigid lifting arms
    • Base with anti-tilting board on front and sides, and four wheels to move the ladder
    • Two wheels with brake at adjustable heights to ensure absolute stability
    • Adjustable stabiliser brackets on the sides
    • Universal joints
    • Ideal for tanker trucks, tanks, vehicles, etc.
    Read More

    LATERAL SLIDING LADDER

  • Lateral sliding ladder
  • Welded structure for optimal rigidity and stability
  • Moved by means of sliding trolley and four wheels at the base
  • Sturdy anti-slip steps
  • Railings on three sides pursuant to the applicable regulations
  • Object tray
  • Comfortable platform with anti-slip surface, equipped with foot stop on three sides pursuant to the applicable regulations
  • Ideal for shelving, warehouses, cemetery use, etc.
  • Rail height and length as requested
  • Read More

    NYLON LADDER + ALUMINIUM STEPS



    • Rope ladder
    • Nylon uprights 16 mm in diameter
    • Anti-slip aluminium rungs, 25 mm in diameter
    • Hooks with double safety karabiner
    • Width: 350 mm
    • Recommended to access particular zones, such as wells or tanks that cannot be reached with normal ladders

    MANDATORY SAFETY KITS WHEN 5 M HEIGHT IS EXCEEDED

    LENGTHS AS REQUESTED
    Read More

    SPECIAL LIFTING PLATFORM





    • Special lifting platform
    • Initially conceived for painting booths, over the years it has found applications in various sectors, thanks to the versatility with which it can be customised
    • Dimensions and final height of platform, in fact, may vary as a function of customer needs and both the translation on the ground and the lifting of the basket may be obtained both manually and electrically
    • Swivel wheels with brake
    • Pushbutton panel at ground level or aboard the basket (electrical version)
    • Fixed side or with latch system
    • Railing Motor casing
    • Battery casing
    • Chain casing
    • Man-present safety device protected against accidental activation
    • Opening gate
    • Access steps to platform
    • Screw type stabilisers with locking pins



    Platform dimensions and height as requested
    Read More

    SCISSOR LIFTING PLATFORM ON WHEELS



    • Scissor lifting platform on wheels
    • Powered from armoured battery with automatic battery charger (6V 240 A/H with 10 hour charge)
    • Extensible cantilever basket (1 m) with self-draining platform and view of area underneath
    • Controls aboard the basket
    • Extensible cantilever basket (1 m) with self-draining platform and view of area underneath
    • Entry gate that closes automatically
    • Height of work platform from 5.90 to 10.2 m
    • Translation at max height For indoor and outdoor use 220V power outlet on basket edge, with circuit breaker
    • Solid rubber puncture-proof wheels, non-staining on request
    • Planarity indicators
    • Available in version with manual translation, complete with fixed or removable stabilisers
    Read More

    SCISSOR LIFTING PLATFORM ON TRACKS



    • Scissor lifting platform on tracks
    • Extensible cantilever basket (1 m) with self-draining platform and view of area underneath
    • Rubber covered tracks
    • Easy access to work platform and entry gate that closes automatically
    • Powered by i.c. (petrol) engine
    • Protective railings that are easily removed for transport
    • Hydraulic stabilisers with independent control
    Read More
    COFFIN LIFT 2020

    COFFIN LIFT

    • Coffin lift for burials
    • Operated by one person
    • Electro-welded structure in structural steel
    • Sliding rail consisting of an extruded aluminium profile
    • Puncture proof wheels with large tread for gravelly terrain (rear wheels about 260 mm in diameter and twinned front wheel with rudder, about 260 mm in diameter)
    • Four removable height adjustable stabilisers to level the equipment
    • Removable basket
    • Coffin supporting surface on rollers, can be closed to reduce overall dimensions in resting position
    • Belts with ratchet to secure the coffin to the roller supporting surface during lifting stage
    • Manual lifting of roller supporting surface to 3 levels

      TECNICHAL DATA

      • Min. height of operator basket 400 mm
      • Max. height of operator basket 2990 mm
      • Min. height of coffin supporting surface 1000 mm
      • Max. burial height 4200 mm
      • Overall capacity 320 kg
      • Capacity of coffin supporting surface 200 kg
      • Capacity of operator basket floor 120 kg
      • Overall dimensions in resting position 780 x 1580 x H 1980 mm
      • Overall dimensions in working position, about 1400 x 1700 x H 4500 mm
      • Dimensions of coffin supporting surface 400 x 1250 mm

      MODELS

      AF M

        • * Manual version
        • * Lifting by means of double-acting oleo dynamic pump and free descent at controlled speed
        • * In the standard version, the pump is mounted on the frame, on request it can placed aboard the basket
        * Weight 275 kg

      AF CC

        • * Electric version with DC motor
        • * Lifting by means of electrical control unit with 24V DC motor powered from batteries
        • * Battery charger and manual emergency pump
        • * Power supply of traction accumulators 2 x 60 Ah 12V
        • * Input power 1.2 kW
        • * Controlled by means of fixed pushbutton panel aboard the basket
        * Weight 320 kg


      AF CA

        • * Electric version with single phase 230V-50Hz AC motor
        • * Lifting by means of electrical control unit
        • * Input power 1,1 KW
        • * Manually operated emergency pump
        • * Controlled by means of pendant pushbutton panel aboard the basket
        • * Switchgear in thermoplastic enclosure
        * Weight 310 kg
    Read More

    COFFIN LIFTS FOR CHAPELS



    • Coffin lifts for burials
    • Ideal for use in chapels on account of its overall dimensions even smaller than the standard version
    • Can be operated by a one person
    • Structure in electro-welded structural steel
    • Sliding rail consisting of an extruded aluminium profile
    • Puncture proof wheels with large tread for gravelly terrain (rear wheels about 260 mm in diameter and twinned front wheel with rudder, about 260 mm in diameter)
    • Four removable height adjustable stabilisers to level the equipment
    • Removable basket
    • Coffin supporting surface on rollers, can be closed to reduce overall dimensions in resting position
    • Belts with ratchets to secure the coffin to the roller supporting surface during lifting stage
    • Manual lifting of roller supporting surface to 3 levels

    TECHNICAL DATA

    • Min. height of operator basket 400 mm
    • Max. Height of operator basket 2990 mm
    • Min. height of coffin supporting surface 1000 mm
    • Max. burial height 4200 mm
    • Overall capacity 320 kg
    • Capacity of coffin supporting surface 200 kg
    • Capacity of operator basket floor 120 kg
    • Overall dimensions in resting position 780 x 1580 x H 1980 mm
    • Overall dimensions in working position, about 1420 x 1580 x H 4500 mm
    • Dimensions of coffin supporting surface 400 x 1250 mm

    MODELS

    MODEL AF/S M

    • Manual version
    • Lifting by means of double-acting oleo dynamic pump and free descent at controlled speed
    • In the standard version, the pump is mounted on the frame, on request it can placed aboard the basket
    • Weight 275 kg

    MODEL AF/S CC

    • Electric version with DC motor
    • Lifting by means of electrical control unit with 24 V DC motor powered from batteries
    • Battery charger and manual emergency pump
    • Power supply of traction accumulators 2 x 60 Ah 12V
    • Input power 1.2 kW
    • Controlled by means of fixed pushbutton panel in the basket
    • Weight 320 kg

    MODELLO AF/S CA

    • Electric version with single phase 230V-50Hz AC motor
    • Lifting by means of electrical control unit
    • Input power 1.1 kW
    • Manual pump for use in an emergency
    • Controlled by means of pendant control panel in the basket
    • Switchgear in thermoplastic enclosure
    • Weight 310 kg
    Read More

    COFFIN TROLLEYS



    • Coffin trolley
    • Available in standard version or with removable aluminium stretcher with four handles
    • Aluminium structure
    • Overall dimensions: 75 mm high, 800 mm wide and 2100 mm long
    • Base fitted out with four tyre rubber wheels, diam. 260 mm x 85 mm, two of them fixed and two swivel with brakes
    Read More

    COFFIN LOWERING DEVICE





    • Coffin lowering devices in electrically galvanised structural steel
    • Composition of the structure: two side members joined by a cross-member
    • Four swivel wheels made of puncture-proof or tyre rubber, 260 mm in diameter
    • Manual hoist with worm screws
    • Ropes moving on pulleys mounted on sealed bearings
    • Movable cross-members connected to the lifting ropes and the two belts with ratchet for the coffin harness

    TECHNICAL DATA

    • Max capacity 250 kg
    • Overall dimensions at base 2850 x 1160 x H 1900 mm
    • Total weight 130 kg
    • Max vertical stroke 4200 mm
    Read More

    SINGLE SEGMENT FOLDING WOODEN LADDER



    • Single segment folding ladders
    • Beech wood ladder
    • The ideal step ladder for the home, stores, warehouses
    • Made with attention to detail, combines functionality and elegance
    • All the wooden parts are fixed with special glues and galvanised screws
    • Safety device to prevent accidental closing
    • Anti-slip corrugated 80 mm steps
    • Anti-slip rubber feet
    Read More

    SINGLE SEGMENT FOLDING LADDER

    • Single segment folding ladder
    • Extra light aluminium ladder
    • Light and easy to handle, conceived for those seeking the quality of a safe product combined with an excellent price ratio
    • Anti-slip corrugated steps welded to the uprights of the ladder
    • Tilting platform
    • Protection pursuant to the regulations
    • Anti-slip rubber feet
    Read More

    ELEGANT STEP STOOL



    • Elegant step stool in solid wood
    • Ideal for a library, study, living room, kitchen
    • Wide treads to accommodate the foot in full comfort
    • Made with attention to detail and stylish finishes
    • Available in beech wood with choice of natural, cherry wood and wengè finishes
    • Anti-slip rubber feet
    • Protection on last step
    Read More

    ELEGANT FOLDING LADDER

    • Elegant ladder in solid wood
    • The large treads, wide platform, double blocking system at the top and absolute stability make it into a comfortable, handy and safety tools for the home, from the study to the kitchen, and for office
    • Made with attention to detail and stylish finishes
    • Available in beech wood with cherry wood finish
    • Anti-slip rubber feet
    • When closed, thanks to the tilting protection, it takes up very little space and thanks to the wheels it can be moved with ease without lifting it
    Read More

    FOLDING STOOL

    • Practical retractable stool which, thanks to the folding steps, can also be used as a solid ladder.
    • Reliable, safe and indispensable.
    • Elegant piece of furniture, perfectly finished
    • Useful for reaching the highest shelves of cabinets and shelves.
    • Minimum dimensions when closed.
    • First choice beechwood structure, available in several versions and colors.
    • Large upper shelf.
    Read More
